Bore finder

Slide to the bore you're designing around. You'll get the outside diameters that run against it, the wall left over, the weight per metre, and the H8 tolerance band that applies at that size.

Drag or tap the scale Bore Ø, mm
Cross-section of the selected tube Ø100 Ø120 outside t 10.0

Wall and bore are drawn to their true ratio. The section is not drawn to absolute scale between sizes.

Bore100mm
Outside120mm
Wall10.0mm
Weight27.13kg/m
Outside diameters against Ø100
5 options

Bore tolerance at this size: +0.054 / 0 mm (H8). Other sizes made to order.
